300w 137-960mhzTaaper 10dB N-F Repeater Accessories Antenna And Feeder

Brand Name: MSTAR
Model Number: MNPT-0628-02-NF
MOQ: 1
Price: 14
Packaging Details: 25*20*10cm Piece/Pieces
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Detail Information
Product Description
Detail Information
Supply Ability:
100 Piece/Pieces 7days
Highlight:

960mhz Repeater Accessories Antenna And Feeder

,

300w Repeater Accessories Antenna And Feeder

Product Description
Normal Specification for power tapper:
Model No. MNPT-0628-02-NF
Freq(MHz) 137-960MHz
Ratio, nom. 10:1/10dB
Output/Split -0.9/-10.4
Branch Flatness ref. to Input Level, incl Loss, dB -11.0±0.8@137-200MHz
-10.7±0.7@200-250MHz
-10.3±0.7@250-380MHz
-10.1±0.7@380-520MHz
-9.9±0.5@698-960MHz
Input VSWR max 1.20@147-380MHz
1.20@380-960MHz
Power(W) 300
Impedance 50 ohm
Connector N-female
Color Red
Temp(deg) -35~+75
Application Outdoor, IP65
