| Brand Name: | MSTAR |
| Model Number: | LX15-5B |
| MOQ: | 1 |
| Price: | 1326 |
| Packaging Details: | 25*20*10cm Piece/Pieces |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Items | Uplink | Downlink | ||
| Frequency Range | Band 12 | 704~716 MHz | 734~746 MHz | |
| Band 13 | 776~787 MHz | 746~757 MHz | ||
| Band 5 | 824~849 MHz | 869~894 MHz | ||
| Band 4 | 1710~1755 MHz | 2110~2155 MHz | ||
| Band 2 | 1850~1910 MHz | 1930 -1990 MHz | ||
| Output Power | 10± 2d8m | 15± 2dBm | ||
| Gain | 60± 2dB | 60±2dB | ||
| Ripple | Band 12 | ≤8 dB | ≤8 dB | |
| Band 13 | ≤8 dB | ≤8 dB | ||
| Band 5 | ≤8 dB | ≤8 dB | ||
| Band 4 | ≤8 dB | ≤8 dB | ||
| Band 2 | ≤15 dB | ≤15 dB | ||
| Max.Input | Power Without Damage | -10 dBm | -10 dBm | |
| Spurious Emission | 9KHz~1GHz | ≤-36 dBm | ≤-36 dBm | |
| 1GHz~12.75GHz | ≤-30 dBm | ≤-30 dBm | ||
| ALC Active 20dB | ≤2dB | ≤2dB | ||
| Alarm | ALC not Active | Green | ||
| ALC Active 5~10dB | Orange | |||
| ALC Active 15~20dB | Red | |||
| Self-oscillation | Red Flashing | |||
| (uplink OFF) | ||||
| Time Delay | ≤0.5 μs | ≤0.5 μs | ||
| Power Supply | DC:5 V | |||
| Power Consumption | <20W | |||
| RF Connector | N-Female | |||
|
|
