| Brand Name: | mstar |
| Model Number: | MNPS-190-03-NF |
| MOQ: | 1 |
| Price: | 36 |
| Packaging Details: | 25*20*10cm Piece/Pieces |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Model No. | MNPS - 190 - 02 - NF | ||
|---|---|---|---|
| Freq(MHz) | 138 - 960 | ||
| Input Port Number | 1 | ||
| Output Port Number | 2 | 3 | 4 |
| Split Loss(dB) | 3.0 | 4.8 | 6.0 |
| IL(dB) | 0.6 | 1.0 | 1.0 |
| Isolation | 20 | 17 | 17 |
| VSWR | ≤1.30 | ||
| PIM(dBc) | ≤ - 153dBc@2*43dBm | ||
| Total Input Power(W) | 50 | ||
| Impedance | 50 ohm | ||
| Connector | N - female | ||
| Color | Black | ||
| Temp(deg) | -30 - +70 | ||
| Application | Indoor or Outdoor, IP65 |
|
|
