| Brand Name: | mstar |
| Model Number: | MWPS-400-02-NF |
| MOQ: | 1 |
| Price: | 10 |
| Packaging Details: | 25*20*10cm Piece/Pieces |
| Payment Terms: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
Model No MWPS-400-02-NF MWPS-400-03-NF MWPS-400-04-NF
Freq(MHz) 400-470
Input Port Number 1 1 1
Output Port Number 2 3 4
Split Loss(dB) 3.0 4.8 6.0
IL(dB) ≤0.5 ≤0.6 ≤0.7
Isolation 20 20 20
VSWR ≤1.25
Total Input Power(W) 300
Impedance 50 ohm
Connector N-female
Color Black-plated
Temp(deg) -30~+70
Application Indoor IP65
|
|
